Product Summary

The LPC1754FBD80 is an ARM Cortex-M3 based microcontroller. It is embedded applications featuring a high level of integration and low power consumption. The ARM Cortex-M3 is a next generation core that offers system enhancements such as enhanced debug features and a higher level of support block integration.The applications of the LPC1754FBD80 are eMetering, Lighting, Industrial networking, Alarm systems, White goods, Motor control.

Parametrics

LPC1754FBD80 absolute maximum ratings: (1)VDD(3V3) supply voltage (3.3 V): 2.4V to +3.6V ; (2)VREG(3V3) Voltage regulator supply voltage (3.3 V): 2.4V to +3.6V; (3)Vi(VBAT) input voltage on pin VBAT: -0.5V to +4.6V; (4)Vi(VREFP) input voltage on pin VREFP: -0.5V to +4.6V; (5)IDD supply current: 100mA; (6)Tstg storage temperature: -40℃ to +150℃; (7)Ptot(pack) total power dissipation (per package): 1.5W.

Features

LPC1754FBD80 features: (1)ARM Cortex-M3 processor, running at frequencies of up to 80 MHz. A Memory Protection Unit (MPU) supporting eight regions is included; (2)ARM Cortex-M3 built-in Nested Vectored Interrupt Controller (NVIC); (3)256 kB on-chip flash programmimg memory. Enhanced flash memory accelerator enables high-speed 80 MHz operation with zero wait states; (4)In-System Programming (ISP) and In-Application Programming (IAP) via on-chip boot loader software.

Diagrams

LPC1754FBD80 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LPC1754FBD80,518
LPC1754FBD80,518
NXP Semiconductors
8-bit Microcontrollers (MCU) CORTEX-M3 128 KB FL 32 KB SRAM USB 2.0
Data Sheet
0-645: $3.07
645-1000: $2.67
1000-2000: $2.57
LPC1754FBD80,551
LPC1754FBD80,551
NXP Semiconductors
ARM Microcontrollers (MCU) ARM Cortex M3 Micro Controller
Data Sheet
0-1: $4.45
1-25: $3.59
25-100: $2.93
100-250: $2.80
