Product Summary

The fdb039n06 is an N-Channel PowerTrench MOSFET. The fdb039n06 is produced using Fairchild Semiconductor advanced PowerTrench process that hs been especially tailored to minimize the on-state resistance and yet maintain superior switching performance. Applications of the fdb039n06 include: DC to DC convertors / Synchronous Rectification.

Parametrics

fdb039n06 absolute maximum ratings: (1) Drain to Source Voltage VDSS: 60V; (2) Gate to Source Voltage VGS: ±20V; (3) Drain Current ID: 696A; (4) Single Pulsed Avalanche Energy EAS: 872mJ; (5) Peak Diode Recovery dv/dt: 7V/ns; (6) Power Dissipation PD: 231mW (Tc=25°C) , 1.54W/°C (Derate above 25°C) ; (6) Operating and Storage Temperature Range Tj, TSTG: -55 to 175°C; (7) Maximum Lead Temperature for Soldering Purpose, 1/8 inch from Case for 5 Second TL: 300°C.

Features

fdb039n06 features: (1) RDS (on) =2.95mΩ (Typ.) @VGS=10V, ID=75A; (2) Fast Switching Speed; (3) Low Gate Charge; (4) High Performance Trench Technology for Extremely Low RDS (on) ; (4) High Power and Current Handling Capability; (5) RoHS Compliant.

Diagrams

fdb039n06 Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FDB039N06
FDB039N06

Fairchild Semiconductor

MOSFET PT3 Low Qg 60V, 3.9Mohm

Data Sheet

0-1: $2.57
1-25: $2.07
25-100: $1.88
100-250: $1.70
