Product Summary

The 1.5SMC350A is a silicon avalanche diode.

Parametrics

1.5SMC350A absolute maximum ratings: (1)Peak pulse power dissipation on 10/1000μs waveform (Note 1.2,FIG.1): Min 1500 Watts; (2)Peak pulse current of on 10/1000μs waveform (Note 1, FIG.3): See Table 1 Amps; (3)Peak forward surge current, 8.3ms single half sine-wave superimposed on rated load, (JEDEC Method)(Note3): 200 Amps; (4)Operating junction and Storage temperature range: -55 to +150 °C.

Features

1.5SMC350A features: (1)RoHS compliant; (2)For surface mounted applications in order to optimize board space; (3)Low profile package; (4)Built-in strain relief; (5)Glass passivated junction; (6)Low Inductance; (7)Excellent clamping capability; (8)Repetition Rate (duty cycle):0.05%; (9)Fast response time: typically less than 1.0ps from 0 Volts to BV min; (10)Typical IR less than 1μA above 10V; (11)High temperature soldering: 250°C/10 seconds at terminals.

Diagrams

1.5SMC350A pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
1.5SMC350A
1.5SMC350A

Littelfuse

TVS Diodes - Transient Voltage Suppressors 1.5SMC350A

Data Sheet

0-1: $0.53
1-25: $0.49
25-100: $0.41
100-250: $0.36
1.5SMC350A/57T
1.5SMC350A/57T

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect

Data Sheet

Negotiable
1.5SMC350A-E3/57T
1.5SMC350A-E3/57T

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect

Data Sheet

0-1: $0.53
1-10: $0.48
10-100: $0.44
100-250: $0.41
1.5SMC350A-E3/51T
1.5SMC350A-E3/51T

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect

Data Sheet

Negotiable
1.5SMC350A-E3/59T
1.5SMC350A-E3/59T

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect

Data Sheet

Negotiable
1.5SMC350A/9AT
1.5SMC350A/9AT

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V Unidirect

Data Sheet

Negotiable
1.5SMC350AHE3/57T
1.5SMC350AHE3/57T

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V 5% Unidir

Data Sheet

0-850: $0.40
850-960: $0.40
960-1000: $0.38
1000-2000: $0.36
1.5SMC350AHE3/9AT
1.5SMC350AHE3/9AT

Vishay Semiconductors

TVS Diodes - Transient Voltage Suppressors 1500W 350V 5% Unidir

Data Sheet

0-2070: $0.38
2070-3500: $0.36
3500-7000: $0.34
